Discharge Size: 0.2-5 (mm)
Processing Capacity: 6-310 (t/h)
Application Fields: mining, water conservancy and hydropower
Applied Material: ore, rock, artificial aggregate
The energy-efficient rod mill that our company produces is all that rolling bearing support instead of bearing bush slip bearing support. It will save 10-20% energy compared with slip bearing support and improve production capacity by 10-20% due to the poor liquidity of dry method manufacturing ,the capacity is 40%～70% of wet method manufacturing.
1.Discharge forms are all centeral discharge except for “GMBZ” series, and feed from hoppers.
2.The layout of equipment can be customized according to the demands of users and non-standard design and manufacture is also acceptable.
The electromotor drives the cylinder to rotate through reduction gear. Under the friction force and centrifugal force the crushed ores inside the cylinder and the steel rod are lifted to a certain height by the lining plate and fall down. The ores are gradually crushed by impacting and grinding, and finally are discharged from the cylinder.
| Model | Barrel Size (mm) | Barrel Volume(m3) | Rod Load (t) | Speed(r/min) | Power | Outlet Size | Capacity |
| Dia. × Length | (mm) | (t/h) | |||||
| GMBZ1535 | φ1500×3500 | 5.9 | 8 | 23 | 90 | 2.5-0.2 | 15-6 |
| GMBZ1835 | φ1800×3500 | 7.9 | 13 | 22.8 | 160 | 2.5-0.2 | 25-10 |
| GMBZ2130 | φ2100×3000 | 9.2 | 17 | 20.9 | 185 | 2.5-0.2 | 32-13 |
| GMBZ2136 | φ2100×3600 | 11.0 | 18 | 20.9 | 210 | 5-0.8 | 38-15 |
| GMBZ2140 | φ2100×4000 | 12.2 | 19 | 20.9 | 220 | 5-0.8 | 43-17 |
| GMBZ2145 | φ2100×4500 | 13.8 | 20 | 20.9 | 250 | 5-0.8 | 49-20 |
| GMBZ2442 | φ2400×4200 | 17 | 21 | 19 | 355 | 5-0.8 | 58-24 |
| GMBZ2445 | φ2400×4500 | 18.2 | 23 | 19 | 355 | 5-0.8 | 63-27 |
| GMBZ2736 | φ2700×3600 | 18.4 | 24 | 17.5 | 400 | 5-0.8 | 82-33 |
| GMBZ2745 | φ2700×4500 | 22.4 | 27 | 17.5 | 500 | 5-0.8 | 90-36 |
| GMBZ3050 | φ3000×5000 | 31.9 | 46 | 17.3 | 630 | 5-0.8 | 140-50 |
| GMBZ3250 | φ3200×5000 | 35.7 | 52 | 16.37 | 800 | 5-0.8 | 185-70 |
| GMBZ3460 | φ3400×6000 | 49.2 | 72 | 15.53 | 1120 | 5-0.8 | 220-85 |
| GMBZ3660 | φ3600×6000 | 55.1 | 80 | 14.98 | 1250 | 5-0.8 | 260-105 |
| GMBZ4060 | φ4000×6000 | 69.8 | 102 | 13.53 | 1600 | 5-0.8 | 310-130 |
