Discharge granularity: ≤3,70-90%
Processing Capacity: 8-120（t/h）
Application Fields: it is mainly used in small and medium cement plant.
Applied material: medium soft iron ore, sandstone, blast furnace slag, coal gangue, lump coal, metallurgy solvent, etc.
PFL series crushers are developed by our company which combined with domestic and overseas advanced technology. The machine has features such as simple structure, large ratio of crushing, low energy consumption, stable rotation, easy operation and maintenance etc.
After the material fall into the crushing chamber, firstly will be thrown towards the reaction liner by feed tray at high speed, then fall into the sapce between the hammerhead and reaction liner. The material will become smaller from the big size by heating, crushing , grinding of hammerhead, and finally, crushed into small granule and discharged from the crusher.
| Model | Max. Feed Size（mm） | Discharge Size（mm） | Mainshaft Speed(r/min) | Capacity(t/h） | Power（kw） |
| PFL-750Ⅲ | ≤100 | ≤3,70-90% | 800-1350 | 8 -20 | 45 |
| PFL-1000Ⅲ | ≤120 | ≤3,70-90% | 650-980 | 15-30 | 55 |
| PFL-1250Ⅲ | ≤150 | ≤3,70-90% | 510-770 | 30-45 | 90 |
| PFL-1500Ⅲ | ≤180 | ≤3,70-90% | 430-640 | 50-70 | 132 |
| PFL-1750Ⅲ | ≤200 | ≤3,70-90% | 420-540 | 70-100 | 160 |
| PFL-2000Ⅲ | ≤220 | ≤3,70-90% | 360-500 | 90-120 | 200 |
| PFL-2300Ⅲ | ≤240 | ≤3,70-90% | 330-450 | 120-160 | 250 |
| PFL-2500Ⅲ | ≤240 | ≤3,70-90% | 300-420 | 160-200 | 355 |
