The GZG vibrating feeder is a trough-type feeder that uses a vibrating motor as its vibration source. It is mainly used to uniformly, continuously, and quantitatively feed loose bulk materials, granular materials, and powdered materials from storage bins to related receiving equipment. It is widely applicable in industries such as water conservancy, hydropower, mining, metallurgy, coal, building materials, chemical, and construction. It serves as a supporting equipment in various mineral and rock processing systems, providing a simple, practical, and efficient storage and feeding solution. This series of vibrating feeders can also be equipped with variable frequency vibrating motors to adjust and control the feeding rate as needed. Additionally, they can be configured with a closed structure based on the specific requirements of the materials or operating conditions. The feeder can be installed in both suspended and seated forms.
This series of vibrating feeders feature simple structure, high feeding capacity, small size, high efficiency, light weight, low power consumption, quick startup, smooth stopping, low noise, minimal wear, reliable operation, and easy maintenance.
Application areas: Water conservancy, hydropower, mining, metallurgy, coal, building materials, chemical, and construction.
Applicable materials: Loose bulk materials, granular materials, and powdered materials.
| Mode |
Feeder trough dimensions (cm) |
Feeding capacity(t/h r=t/㎥) |
Maximum feeding capacity Granularity or particle size(mm) |
Vibrator speed or vibration motor speed (r/min) |
Vibration amplitude (Bi-modal) |
Power (KW) |
|
| Horizontal | Downward tilt of 10° | ||||||
| GZG50-90 | 50×90×16 | 60 | 85 | 150 |
1450 |
4.0 | 2×0.25 |
| GZG63-100 | 63×100×18 | 110 | 150 | 200 |
2x0.55 |
||
| GZG70-110 | 70×110×20 | 120 | 170 | ||||
| GZG80-120 | 80×120×25 | 160 | 230 | 250 | 2x0.75 | ||
| GZG90-145 | 90×145×30 | 180 | 250 | ||||
| GZG100-150 | 100×150×30 | 270 | 380 | 300 |
2x1.1 |
||
| GZG110-150 | 110×150×30 | 300 | 420 | ||||
| GZG125-150 | 125×150×37 | 460 | 650 | 350 | 2x1.5 | ||
| GZG130-150 | 130×150×37 | 480 | 670 | ||||
| GZG150-180 | 150×180×37 | 720 | 1000 | 500 | 3.5 | 2x2.2 | |
| GZG160-200 | 160×200×37 | 770 | 1100 | 4.0 | |||
| GZG180-200 | 180×200×37 | 900 | 1200 | 3.0 | 2x3.0 | ||
| GZG200-200 | 200×200×37 | 1000 | 1400 | 2.5 | |||
