The DJ series large incline sidewall belt conveyor is a relatively new type of belt conveyor that uses a corrugated sidewall belt instead of a conventional conveyor belt. Its structural characteristics make it have many advantages, such as simple structure, easy maintenance, smooth operation, reliable performance, low energy consumption, and low noise. In particular, it can achieve large inclination conveying (0°-90°), which reduces the overall length of the conveyor and minimizes the required floor space. It is widely used in the transportation of bulk materials in ports, terminals, metallurgy, chemical industry, power generation, coal mining, and construction materials.
Application fields: Ports, terminals, metallurgy, chemical industry, power generation, coal mining, construction materials.
Applicable materials: Transportation of bulk materials.
| Belt width(mm) | Sidewall height(mm) |
Max. conveying capacity (m3/m) |
Inclination angle(°) | Belt speed(m/s) | Power(kw) |
| 500 | 80 | 78 | 30-90 | 0.8-2.0 | 1.5-18.5 |
| 120 | 104 | ||||
| 160 | 130 | ||||
| 650 | 80 | 118 | 30-90 | 0.8-2.0 | 1.5-22 |
| 120 | 156 | ||||
| 160 | 210 | ||||
| 800 | 120 | 248 | 30-90 | 0.8-2.0 | 2.2-45 |
| 160 | 340 | ||||
| 200 | 370 | ||||
| 1000 | 160 | 465 | 30-90 | 0.8-2.0 | 4-75 |
| 200 | 518 | ||||
| 240 | 708 | ||||
| 1200 | 160 | 702 | 30-90 | 0.8-2.0 | 5.5-110 |
| 200 | 788 | ||||
| 240 | 1077 | ||||
| 300 | 1292 | ||||
| 1400 | 200 | 942 | 30-90 | 0.8-2.0 | 5.5-160 |
| 240 | 1392 | ||||
| 300 | 1613 | ||||
| 400 | 2457 | ||||
| 1600 | 200 | 1118 | 30-90 | 0.8-2.0 | 5.5-160 |
| 240 | 1578 | ||||
| 300 | 1934 | ||||
| 400 | 2961 |
